Blockchain and supply chains

By Glenn Johnson, Editor
Friday, 07 June, 2019

Is the latest darling of IT ready for the world of supply chains?

It seems that some subjects are dogging us daily in the automation and process control sector — terms like Industry 4.0, smart manufacturing, IIoT and big data are bandied around so much that this editor (and I suspect many other readers) feel like we are sorely in need of something else to read about. It seems every company that has anything to do with industrial automation or associated technology has to have its “me too” flag waving, for fear of being seen as behind the times.

Now another subject is getting more and more attention: blockchain technology — another technology that is promised by many to be the panacea for many ills. Is it really? As it turns out, there is some debate about that.

One major area of interest in the application of blockchain technology is the management of today’s global supply chains — an integral part of any large manufacturing or process industry business. The complexity of modern supply chains, and a need for much greater transparency, is what is creating interest in the adaptation of blockchain technology to supply chains. It is believed to offer an opportunity to tackle some of the perennial issues that compromise supply chain effectiveness, such as the lack of traceability.

First let’s look at why it is of interest by way of some examples:

Tracing and recalls

One example being discussed is using blockchain to track products and improve crisis handling. For example, in the case of a food-borne illness, once the product responsible is identified, blockchain can be used to check the audit trail, including the origins of its ingredients and the ingredient that is causing the issue. With the source of contamination identified, the authorities can focus on recalling the products affected. US company Walmart did a blockchain pilot in China that enabled them to trace a package of mangoes from store to farm in a few seconds. Previously, this would have taken days or weeks.¹

Counterfeit prevention

Another example is the detection of counterfeit products. Here in Australia, the wine industry has had examples of the damage such activity can do. In March 2018, Chinese police seized some 50,000 counterfeit bottles of Australian wine.² Using blockchain, retailers can provide customers with indisputable proof of the provenance and authenticity of their products. A tech start-up in Australia is using blockchain technology to combat the counterfeiting of wine bottles exported from Australia.³

Replacing slow manual processes

Modern supply chains can currently handle large, complex data sets. However, many processes still exist, especially those in lower supply tiers such as at the farm level in a food supply chain, or in the shipping industry, that are slow and rely entirely on paper.

How it works

For those who don’t know what a blockchain is, it is basically a chain of ‘ledger transactions’.

Imagine a bunch of blocks of transaction data (Figure 1).

Figure 1: A set of unlinked blocks of transaction data. (Source: GoodAudience.com)

Figure 1: A set of unlinked blocks of transaction data. (Source: GoodAudience.com⁴)

In the Figure, Block 1 shows 12 transactions and Block 2 has the next 15. If we now create a cryptographic hash function of Block 1 and add it to the end of Block 2 as a new piece of data, then Block 1 is cryptographically chained to Block 2. Repeating the process, creating a cryptographic hash function of Block 2, including Block 1’s hash and adding it to Block 3 now adds both Block 1 and Block 2 into a chain with Block 3. So each block’s hash function is dependent on all blocks that came before (Figure 2).

Figure 2: Linking blocks of transaction data into a blockchain. (Source: GoodAudience.com)

Figure 2: Linking blocks of transaction data into a blockchain. (Source: GoodAudience.com⁵)

The result is that the chain can be stored in many places, available to public access (in the case of Bitcoin), yet it remains an immutable ledger of all the transactions. For a blockchain to work, all computing nodes storing the chain need to establish a consensus on the truth of the blockchain. It is protected from alteration by virtue of the fact that a change to even a single bit of data in a single block will dramatically change its hash function, and it will no longer chain with the next block.

So if Block 1 is changed it will no longer link to Block 2, making the alteration apparent to all systems and users involved in the chain. They therefore reject this change by shifting back to their previous record of the blockchain where all the blocks are still chained together. The only way to successfully alter data in a block is to then correspondingly alter every other block afterward without detection, which would be a formidable task.

The chain is immutable because of the fact that blockchain is a consensus system. Even if a party has altered a block of transactions and is now trying to calculate new signatures for the subsequent blocks in order to have the rest of the network accept his change, the rest of the network is also calculating new signatures for new blocks. The intruder will have to calculate new signatures for these blocks too as they are being added to the end of the chain. After all, he needs to keep all of the blocks linked, including the new ones constantly being added. Unless the bad actor has more computational power than the rest of the network combined, he will never catch up with the rest of the network finding signatures.

Conflicting opinions

There are many who are claiming that blockchain technology has the potential to turbocharge the effectiveness and profitability of most (if not all) businesses. The supporters of the adoption of blockchain are suggesting that businesses that ignore blockchain technology do so at their peril.

There are, however, some who are saying that blockchain may not be appropriate for supply chains — at least not all of them — and those who have attempted it have struggled to get past a pilot phase.

According to a report published by Gartner⁶ in May, supply chain early adopters are failing to find suitable use cases. The report predicts that “by 2023, 90% of blockchain-based supply chain initiatives will suffer ‘blockchain fatigue’ due to a lack of strong use cases”. The report went on to say that most blockchain supply chain projects “have remained pilot projects due to a combination of technology immaturity, lack of standards, overly ambitious scope and a misunderstanding of how blockchain could, or should, actually help the supply chain”.

Information security: who has permission?

An essential feature of blockchain technology was that it was initially invented to support transactions in Bitcoin, a digital cryptocurrency that operates independently from a central bank, while offering more security than the banking system combined with instantaneous transmission via the internet. Bitcoin is an example of a ‘permissionless’ distributed ledger, residing in the public domain. As a result the Bitcoin blockchain has become increasingly large; however, validation of a single transaction requires only a few previous blocks. Due to the architecture, the parties involved are not known or trusted, but the blockchain itself remains secure from tampering.

In contrast to Bitcoin there are also ‘permissioned’ ledgers that are centralised and governed by ‘actors’, ‘nodes’ or ‘miners’, held outside the public domain. These private blockchains can be established for a smaller group of individuals or organisations to share among themselves. In most supply chains, the parties are known and trusted. The members of the supply chain are also unlikely to accept open access because its users don’t want to reveal proprietary details, such as demand, capacities, orders, prices and margins, at all points of the value chain to unknown participants, as would be the case in a public permissionless system. This means most supply-chain blockchains would need to be governed centrally and restricted to known parties who may be limited to certain segments of data.

Technical challenges

There are a few challenges that need to be overcome before blockchain technology could be in widespread use in supply chains.

Lack of standardisation: There are competing systems currently in use (such as HyperLedger and Ethereum), which means there are no definitive standards on things such as algorithms for consensus (immutability) and which encryption technology to use.
Larger data requirements than Bitcoin: Rather than just simple financial transactions, supply chain blocks will involve significantly larger data sets and greater processing requirements at each step in the chain, even for smaller permissioned systems.
E-commerce systems are already fast: E- commerce makes it possible to take an order, process it and pass it to a distribution centre in close to real time. This already-achieved performance progress leaves less room for blockchain technology to prove its value in verification.
Volume: The large public ledger of Bitcoin requires a huge amount of processing power and energy, but the maximum speed is still only about 450 trillion transactions per second. The predicted transaction workload of supply chains will be much larger. For example, a single car manufacturer can typically generate around 10 billion calls to its suppliers in a 90-day period. Permissioned blockchain technology is still (to date) slower than centralised database systems.
Who will pay?: Bitcoin processing is funded by paying its participants a small fee per block validation. For a supply chain, there are questions to be answered about who will be responsible for the cost of the infrastructure and processing required.

Not ready for prime time?

McKinsey and Company⁷ have suggested that companies need to consider all the facts before jumping in. They say that “blockchain technology may ultimately be a good solution for some types of supply chains, but it is not yet ready for mass adoption”. The company’s view is based partly on the fact that — as Gartner has also said — many pilots conducted so far have failed to deliver the expected value. Also, there are other ways to solve issues of traceability and full transparency, and the gap between blockchain’s current capacity and that needed by supply chains is still too large.

The McKinsey report⁸ suggests that blockchain is best suited to supply chains where participants are not known or trusted, since it can add trust, transparency and traceability. However, for supply chains with known and trusted players, a centralised database approach is generally more than adequate. Even though many existing supply chains use siloed databases that contain data with only limited traceability, nevertheless they do not necessarily need blockchain technology to solve such issues, as they can leverage existing technologies that are better suited to high-volume transactions.

Caution advised

It would seem that organisations need to remain cautious about early adoption of blockchain and not to rush into making it work in their supply chain until there is a clear distinction between hype and its core capability.
